CX-2030 Wood CNC Router With Rotary Spindle
CX-2030 Wood CNC Router With Rotary Spindle can engrave two round materials fixed on the rotary axis at one time, improving the processing efficiency. Suitable for carpentry, wooden doors, furniture, cabinets, molds and other materials of large quantities of processing. The machine use water cooling spindle, long power life, speed up to 18000 r / min, carved smooth surface.
Model:CX-2030
Send Inquiry
Product Description
CX-2030 Wood CNC Router With Rotary Spindle
Product Feature
1.The whole machine body is made from steel seamless welding tempering aging treatment.
2.Servo motor driver 1.5KW, high precision, high speed.
3.25 linear bearing guide, bearing capacity, smooth operation, high precision, long life.
4.2.2KW water cooling spindle, long power life, speed up to 18000 r / min, carved smooth surface.
5.Separate cabinet, split keyboard operation, simple and convenient, easy to learn.
Specification:
|
Model |
CX-2030 CNC Router With Rotary Spindle |
|
X Working Area |
2000mm |
|
Y Working Area |
3000mm |
|
Z Working Area |
400mm |
|
Traveling Positioning Accuracy |
±0.05mm |
|
Repositioning Positioning Accuracy |
±0.05mm |
|
Command Code |
G code |
|
XYZ Axis Structure |
X/Y Rack rail; Z Screw rail |
|
Power |
AC380V / 50Hz |
|
Spindle |
HQD 2.2KW water cooling spindle |
|
Spindle Rotation Speed |
24000rpm / min |
|
Drive Motor |
VEICHI Servo motor1.5KW with breaker |
|
Operating System |
Weihong 4 axis Lambda21A |
|
Linear Rail |
25 Square rail |
Application:
Suitable for carpentry, wooden doors, furniture, cabinets, molds and other materials of large quantities of processing.
