            Automatic loading and unloading ATC CNC Router

            Automatic loading and unloading ATC CNC Router adopts seamless welding tempering aging treatment, no deformation. The spindle adopts HQD air-cooled spindle, the speed can reach 18000 rpm, and the engraving surface is smooth. Equipped with independent cabinet, split keyboard operation. With a vacuum system, it can suck away the wood chips and sundries during the process. Suitable for carpentry, wooden doors, furniture, cabinets, moulds, etc.

            Send Inquiry

            Product Description

            Automatic loading and unloading ATC CNC Router Advantages:
            1.The whole CNC engraving machine body is made from steel seamless welding tempering aging treatment, rigid, no deformation.
            2.The Servo motor of this ATC CNC router is high precision and high speed.
            3. The transmission of the CNC carving machine is Taiwan 25 square rail guide, smooth operation, high precision, long life.
            4. Spindle of the CNC router is HQD air cooling spindle, long power life, speed up to 18000 r / min, carved smooth surface.

            5. With vacuum system, vacuum system can be sucked in the processing process of wood chips and debris, to keep the table clean and indirect maintenance of the equipment.


            Technical Parameters:

            X Working Are

            1300mm

            Y Working Area

            2500mm

            Z Working Area

            200mm

            Countertop structure

            Vacuum adsorption table with clamping wheels

            Command code

            G code

            XYZ Axis transmmision

            X/Y Rack rail; Z Screw rail

            Input Power

            11KW

            Spindle

            HQD 9.0KW,  Air cooling spindle

            Spindle rotation speed

            18000rpm / min

            Inverter

            11KW inverter

            Drive motor

            FUJI servo motor

            Operating system

            Taiwan LNC 2200

            Transmission

            Taiwan LMA 25, ROR1.5

            Vacuum pump power

            7.5KW Air pump

            Linear rail

            Taiwan 25

            Neight Weight

            2500KGS



            Applicable:

            Cabinet door panels, panel furniture, solid wood furniture, indoor composite doors

            Function: Automatic tool change, cutting, milling, hollowing, slotting, punching, etc.
